Description

Overview
The DAH25000 Series delivers ultra high-capacity heating from 25KW to 29KW, representing Durel's solution for the most demanding large-scale industrial thermal processes. Available exclusively in X-Series (600°C) configuration with three-phase 3x400V power, this series is engineered for applications where massive thermal output and continuous operation are essential.

Key Features
Ultra High-Capacity - 25KW to 29KW for maximum thermal output
600°C Capability - High-temperature industrial processing
Re-Circulated Design - Energy-efficient closed-loop heating
Three-Phase 400V - Industrial power standard for maximum efficiency
Enhanced Thermal Tolerance - Max inlet temperature 150°C
High Ambient Rating - Operates in up to 100°C ambient conditions
Protection Class I - Industrial safety certification
Heavy-Duty Construction - Φ145mm and Φ178mm robust body design
Industrial-Grade Mounting - M8 bolt pattern for secure installation

Common Specifications:
Max Inlet Temperature: 150°C
Max Ambient Temperature: 100°C
Max Air Inlet Pressure: 100KPa
Frequency: 50/60Hz
Safety Rating: Protection Class I

Installation Dimensions
DAH25000X Length: 229mm
DAH25000Y Length: 339mm
Body Diameters: Φ145mm, Φ178mm configurations
Air Passages: Multiple diameter options for optimized flow
Mounting: M8-6 industrial bolt pattern

Applications
Ultra-large industrial ovens
High-volume continuous process lines
Large-scale automotive manufacturing
Industrial food processing mega-facilities
Pharmaceutical bulk production
Heavy industrial plastic processing
Large aerospace component production
Industrial glass processing
High-capacity metal treatment
Mega-scale textile operations

Model Selection Guide
DAH25000X Series - Ultra high-capacity applications up to 600°C
DAH25000Y Series - Extreme temperature large-scale processes up to 900°C
Power Selection - Choose based on maximum thermal load requirements
