Durel

Electrofusion Welding Machines

Electra Light W/Scan

Lightweight universal electrofusion machine for pipes 8–48V with data logging.

Other Variants

Elektra M Elektra S Elektra XL 500 Elektra 315

Applications

Pipe welding,

Enquire Now Download Brochure

Description

ELEKTRA LIGHT is an universal electrofusion machine, suitable for welding pipe/fittings for the transport of gas, water and for welding fire sprinkler system (HDPE, PP, PP-R couplings from 8 to 48 V).

The Elektra Light machine is made in compliance with international standards.
This is welding machine’s structure is light weight, so it is extremely easy to carry around.

Composed of:
machine body, an in built memory with 325 welding cycles – report PDF file – featuring the possibility of transferring data to a Pc/Laptop.

STANDARD COMPOSITION
– Elektra Light
– Universal adapter Ø 4,0 – 4,7 mm
– Laser scanner
– Trevira bag
– Manual scraper

ON REQUEST (ACCESSORIES)
Kit for data transfer Machine to Pc/Laptop (adaptor DB9M/USB and Ritmo Transfer)

Technical features

Materials	HDPE/PP/PP-R
Working range	Ø 20 ÷ 125/160 mm
Power supply	110 V single phase 50/60 Hz 230 V single phase 50/60 Hz
Total abdorbed power	1300 W
Max output cu	8 A
60% Duty Cycle output	23 A
Memory capacity	325 reports
Protection degree	IP 54
Dimensions	200x250x210 mm
Weight	7 Kg
