Electrofusion Welding Machines

Elektra 315

HDPE/PP electrofusion unit, Ø8–48V, with 500-weld log, PDF reports, PC transfer.

Other Variants

Elektra M Elektra S Elektra XL Light 500

Applications

Pipe Welding,

Enquire Now Download Brochure

Description

Your reliable and high-performance welding control unit for electrofusion for small and medium diameters.

Elektra 315 is the versatile welder for electrofusion fittings for pressure pipelines in PE, PP, PP-R that welds fittings from 8 ÷ 48 V and up to Ø 315 mm*. Collaboration with multiple partners worldwide has given Ritmo extensive technical knowledge, not tied to a single manufacturer of electrofusion fittings.

* The working range may vary depending on the brand of fittings. Check with the fitting manufacturer for the required welding power and time.

Technical features

Working range	20 ÷ 315 ½” IPS ÷ 10” DIPS (110 V-230V)
Automatic ambient temperature compensation (through the reading of the EF fitting barcode)	Yes
Continuous welding cycle monitoring	Yes
Barcode scanner (ISO 13950)	Yes
Manual welding parameters input	Yes
Connection	Adapter DB9M-USB
Welding report file format	PDF - BIN
Memory	500 cycles
Connector	Universal adapter 90° Ø 4.00 - 4,7 mm
Traceability ISO	12176 - 4
Power supply	110 V - 50/60 Hz 230 V - 50/60 Hz
Absorbed power (Power at 60% Duty Cycle)	2600 W (110 V - 230 V)
Suggested generator	5,5 ÷ 6 kVA
Max output current	100 A
Welding output voltage	8 ÷ 48 V
Outside temperature range	-10° ÷ 50° C; -4° ÷ 122° F
Dimensions Body machine (W x D x H)	263 x 240 x 300 mm 10.3” x 9.4” x 1.8”
Weight Body machine	16 Kg (35.3 lb)
Dimensions transport case (W x D x H)	405 x 285 x 340mm 16” x 11.2”x 13.4”
