Socket fusion

JIG Prime

weld pipes with thermoplastic fittings up to 125 mm in diameter.

Other Variants

125 JIG 90 125 125 light Switch 125

Applications

Pipe welding,

Enquire Now Download Brochure

Description

JIG Prime is Ritmo’s innovative solution for welding pipes with thermoplastic fittings up to 125 mm in diameter. Its lightweight and maneuverability characteristics make JIG Prime an essential tool for working on-site, both vertically and overhead
The welding machine is equipped with two self-centering clamps that, through side knobs, precisely fix the pipe and fitting. With the addition of inserts that act as reducers, the welding machine can work on diameters from 25 to 125 mm. Another distinctive feature of JIG Prime is the reversibility of the clamps that easily detach from the frame and allow adapting the welding machine to on-site work situations

Technical features

Working range	Ø 25÷125 mm
Power supply	110 V Single Phase 50/60 Hz 220-230 V Single Phase 50/60 Hz
Total absorbed power	1400 W
Outside temperature range	-5 ÷ +40°C (23 ÷ 104°F)
Working temperature	180°C ÷ 290°C (356 ÷ 554°F) ± 1%
Time to reach welding temperature	~ 10
Dimensions	506 x 332 x 259 mm; (19.92'' x 13.07'' x 10.2'')
Weight JIG Prime	10,2 Kg (22.49 Ib)
Dimensions transport case	555 x 437 x 326 mm; (21.85 x 17.2 x 12.83)
Weight transport case	5.88 Kg (13 Ib)
